Recommended Grade:
Grade | Grain size(μm) | Density(g/cm³) | Hardness(>=HRA) | TRS(>=MPA) |
TS15 | 0.6 | 14.70 | 92.2 | 3500 |
TS05 | 0.4 | 14.8 | 93.0 | 3300 |
TW08 | 1.4 | 14.75 | 89.5 | 3200 |
TW07 | 1.0 | 14.82 | 91 | 3100 |
Dimension and Tolerance: mm
Length(mm) | Tolerance | Width(mm) | Tolerance | H | Tolerance |
<=80 | +0 /+1.6 | <=10 | +0/+0.5 | <=3.0 | +0/+0.3 |
>80~100 | +0 /+2.5 | >10~20 | +0/+0.6 | >3~5 | +0/+0.4 |
>100~150 | +0 /+3.0 | >20~30 | +0/+0.6 | >5~8 | +0/+0.5 |
>150~200 | +0/+4.0 | >30~40 | +0/+1.0 | >8~10 | +0/+0.8 |
>200~300 | +0/+5.0 | >50 | +0/+1.5 | >10 | +0/+0.8 |
>300 | +0/+6.0 | ---- | --- |
Length: 330 or 310 mm or cut to lengths upon requirement.
Length(mm) | Front straightness(Tol) | Side Straightness (Tol) |
<=80 | <=0.25 | <=0.3 |
>80~100 | <=0.30 | <=0.35 |
>100~150 | <=0.35 | <=0.35 |
>150~200 | <=0.35 | <=0.4 |
>200~300 | <=0.40 | <=0.4 |
>300 | <=0.50 | <=0.5 |
Strips straightness size (mm)
We are accept the size as per the customers’ requirement.
ALSO, we warmly welcome you and your drawing papers.
